a) Latest Bluetooth transmission technology ensures stable data transfer (wireless model).
b) 2.4G wireless transmission mode, low power consumption, long-range, and more efficient transmission (wireless model).
c) Ultra-wide FOV design enhances smooth reading of long barcodes.
d) Outstanding impact resistance and drop durability, making it more robust and reliable.
e) Excellent at reading wrinkled barcodes and complex barcodes.
f) Optimal ergonomic design.
g) Buzzer and vibration alerts for reliable operation in noisy environments.
h) Supports OCR, OPOS, and JPOS.
| Physical Characteristics | |
| Dimensions | 67mmx87mmx183mm |
| Weight | 177g |
| Electrical | |
| ESD | ± 15 KV Air, ± 8 KV Contact |
| Input Voltage | 5V |
| Host System Interfaces | USB, RS232; Key trigger, infrared trigger (KS2000) USB, 2.4G, Bluetooth, supports Bluetooth HID, SPP, BLE (KS2000BT) |
| Environmental Specifications | |
| Drop | 1.5m(VGA); 2m(Mega) steel plate, 18 drops; 5cm, 4000 drops |
| Tumble | 2000hits, 0.5m, Steel |
| Temperature | Operating: -20 to 50 °C; |
| Storage: -40 to 70 °C | |
| Humidity | 0 to 95% relative humidity, non-condensing |
| Light Levels | 0 – 100,000 lux |
| IP | IP52(VGA); IP65(Mega) |
| Reading Performance | |
| Scan Pattern | 640*480(VGA); 1280x800(Mega) |
| Illumination | White LED(VGA) Red and White LED(Mega) |
| Aimer | LED(VGA); Laser(Mega) |
| FOV | VGA:59.3°(D)49.1°(H)37.8°(V) Mega:48°(D)39°(H)29.6°(V) |
| Symbol Contrast | 15% minimum reflectance difference |
| Scan Angle | Pitch: +/- 60°; Roll: +/-180°; Yaw: +/- 60° |
| Min Resolution | 3mil |
| Indicator light | Beeper；LED indicating lamp；Vibration prompt(Mega) |
| Symbologies | |
| 2D Codes | UCC Composite;Aztec;China Sensible Code;Datamatrix;DotCode; QRCode;Micro QRCode;OCR Code |
| 1D / Linear Codes | Code EAN/UPC;GS1DataBar(RSS-14);Code39;Code 128(GS1-128); Code ISBT 128;Code Standard 2of5;Compressed 2of5;Datalogic 2of5; Industrial 2of5;Interleaved 2of5 (l2of5);Matrix 2of5;Codabar;Code11 Code93;MSI;Plessey;BC412;ISSN |
| Postal Codes | Australian Post; British Post; China Post; IMB; Japanese Post; KIX Post; Korea Post; Planet Code; Postnet; Royal Mail Code |
| Stacked Codes | EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites |
| DOF | |
| Barcode | VGA Mega |
| 3 mil CODE39 | 10 mm - 180 mm 10 mm - 90 mm |
| 13 mil UPC | 5 mm - 380 mm 10 mm - 200 mm |
| 10 mil DM | 10 mm - 180 mm 0 mm - 100 mm |
| 20 mil QR | 0 mm - 300 mm 60 mm - 250 mm |
| Optional Accessory | |
| USB Data Cable, Charging Power Adapter（KS2000BT） | |
