a) Ultra-wide FOV design to improve bar code snappiness especially for long bar code.
b) Global Shutter CMOS Sensor bring much perfect motion tolerance performance.
c) Provides fast and accurate reading of barcodes and extraordinary motion tolerance, even on hard-to-read codes as well as those displayed on mobile phone screens, worn, dirty, poorly printed & bended bar codes.
d) High reading performance on color barcode, inverse barcode and DPM bar code.
a) Ultra slim height, only 6.8 mm. Perfect for integration into ultra-slim devices.
b) Compatible design with some competitor’s product, directly integrated instead.
a) Datalogic Decoding Technology and authorization algorithmic.
b) Flexible technical support on the integration of customer product.
| MECHANICAL | |
| Dimensions | 23,5 mm x 16,2 mm x 6,8 mm |
| WEIGHT | 2.2g |
| ELECTRICAL | |
| Input voltage | VCC 3.1~4.5V, VDDIO 1.7~4.5V |
| Current Consumption | I/O Power current：1mA Supply voltage current：200mA |
| Interface | MIPI |
| Illumination | White LED |
| Aiming | Blue aimer LED |
| ENVIRONMENTAL | |
| Temperature | Storage:-30°C to 70°C Operating: -20°C to 50°C |
| Humidity | 5-95% |
| Shock Rating | 2500 G at 23 °C at 0.85 m sec |
| AMBIENT LIGHT | 0 lux to 100,000 lux |
| PERFORMANCE | |
| Shutter | Global shutter |
| Sensor Pixels | 640 x 480 |
| Field of View | 48° (H) x 34°C (V) |
| Motion Tolerance | EAN/UPC 100% labels: 1m/s @ best focus distance and with illumination system maximum power |
| Symbol Contrast | 25% minimum reflectance |
| Min. Resolution | Linear symbologies : 3mil Datamatrix : 7.5mil ， PFD417 : 6.6mil |
| Scan Angles | Tilt: 360°, Pitch: ± 60, Skew: ± 60 |
| SYMBOLOGIES | |
| Decode Type(2D) | 2D: Aztec Code; China Han Xin Code; Data Matrix; MaxiCode;Micro QR Code; QR Code 2D Stacked:EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites |
| Decode Type(1D) | Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes. |
| Postal | Australian Post; British Post; China Post; IMB; Japanese Post; KIX Post; Korea Post; Planet Code; Postnet; Royal Mail Code (RM4SCC) |
| READ RANGES | |||
DOF | Typical | Guaranteed | |
| 5 mil Code 39 | 5.0 - 19.0 cm | 6.0 - 16.0 cm | |
| 20mil Code 39 | up to 46.0 cm | 8.0 - 37.0 cm | |
| 10mil DataMatrix | 5.0 - 13.0 cm | 6.0 - 11.0 cm | |
| 13mil EAN-13 | 4.0 - 33.0 cm | 4.5 - 27.0 cm | |
